Daewoo Novus M2SEF - 6 X4 Series Chassis Greasing Point Diagram

3-91 INSPECTION AND MAINTENANCE
(2) 6x4 series chassis greasing point diagram
18
2 4 3 14 9 11 13 16 14 19
Engine
Trans-
mission
16 5 14 8 10 7 12 15 14 19 17
MDC0130
1. Bracket support cap sus. upper, left
2. Bracket support cap sus. upper, right
3. Change lever
4. 1st relay
5. 2nd relay
6. Drag link, front
7. Drag link, rear
8. King pin, left, upper
9. King pin, right, upper
10. King pin, left, lower
11. King pin, right, lower
12. Tie rod, left
13. Tie rod, right
14. Spring pin, front
15. Transmission release bearing
16. Transmission release bearing
17. Spring seat, left
18. Spring seat, right
19. Shackle
