3-80 INSPECTION AND MAINTENANCE
10) Valve clearance adjustment
(1) Adjustment intervals
Engine model
DE
DV
DDC
Adjustment intervals
At end of first 1,000km,
Every 10,000km
Every 192,000km
(2) Rated valve clearance(cold)
Engine model
DE
DV
DDC
Valve clearance
Intake: 0.3mm
Exhaust: 0.3mm
Intake: 0.25mm
Exhaust: 0.35mm
Intake: 0.203mm
Exhaust: 0.660mm
(3) Adjustment of valve clearance
Loosen the lock nut of rocker arm adjusting screw,
insert a rated clearance gauge in between the
rocker arm and valve stem, adjust the clearance
with the adjusting screw, and then tighten the lock
nut.
DE Engine
MTC0240
(4) Valve clearance adjustment chart
- DE Engine
Cyl. No. 1 2 3 4 5 6
Valve
in ex in ex in ex in ex in ex in ex
No. 1
6 5 4 3 2 1
No. 6
MDC0080
