Daewoo Novus M2SEF - Clutch Pedal; Parking Brake Lever; Dump Control Lever(for 19;24 Ton Dump Truck)

1-44 HOW TO HANDLE THE VEHICLE
• Clutch pedal
Fully depress the clutch pedal when changing
gears. Do not rest your foot on the pedal when
the clutch is not in use. Premature wear of the
clutch will result.
MTA0960
• Parking brake lever
To set the parking brake, pull up the lever(normal
notch: 9). To release, pull up the lever slightly
and push it down completely with the button on
end of lever depressed fully.
UP
NEUTRAL
MEA0300
DOWN
•
Dump control lever(for 19/24ton dump truck)
If the dump control lever is placed into the "UP"
or "DOWN" position after the PTO lever is pulled
up(at this time the dump control lever returns
to the "NEUTRAL" position simultaneously), the
deck will move up or down.
PTO lever
Caution
• If the dump control lever is moved from the NEUTRAL
position to the DOWN position, the PTO lever also is
MTA0961 pulled down.
• At time of maintenance or when the deck is to be raised
for a long time, make sure that the lever in the cab is
placed in "UP" and moves down the PTO lever.
