1-16 HOW TO HANDLE THE VEHICLE
3) Instruments and indicator lamps
11
10
10
7
1
2
3
4
BULB
CHECK
5 8 11 96
MTD0590
1. Blank 5. Air pressure gauge 9. Illumination control switch
2. Temperature gauge 6. Engine tachometer 10. Turn signal/hazard warning indicator
3. Fuel gauge 7. Tachograph 11. Miscellaneous indicator lamps and
4. Engine oil pressure gauge 8. Bulb check switch warning lamps
(1) Temperature gauge
The gauge indicates the engine coolant
temperature. If the gauge needle stands below
the red colored zone, it means that engine
coolant temperature is normal.
If the needle stands in "H"(overheating), stop
the vehicle and run the engine at a moderately
fast idle speed or put the gear in lower position
to reduce engine load. If the vehicle is operated
in abnormal condition, engine performance will
be reduced and fuel consumption will be
MTA0350
increased.
