Daewoo Novus M2SEF - Page 94

3-89 INSPECTION AND MAINTENANCE
5
•
20.5ton/21ton/22.5ton cargo, 24ton dump vehicles
1. Front front wheel(1st shaft) 2.
Front rear wheel(2nd shaft) 3.
Rear front wheel(3rd shaft) 4.
Rear rear wheel(4th shaft)
5. Spare tire
1 2 3 4
5
1
2
3
MTD0430
4
MTC0431
•
10x4 series
1. Front front wheel(1st shaft) 2.
Front rear wheel(2nd shaft) 3.
Self steer wheel(3rd shaft) 4.
Rear front wheel(4th shaft) 5.
Rear rear wheel(5th shaft)
6. Spare tire
