Daher TBM 930 - Engine Oil; Maximum Certificated Weights; Standard Airplane Weights

Pilot's Operating Handbook
Section 1
General
Edition 1 - January 15, 2018
Rev. 0
Page 1.3.3
Engine oil
System total capacity : 12.7 Quarts (12 litres) (oil cooler included)
Usable capacity : 6 Quarts (5.7 litres)
Maximum oil consumption in 10 hour period : 0.14 qt/hr (0.13 l/hr)
[0.3 lb/hr (0.136 cc/hr)]
Specification
Nominal
viscosity
Specification NATO code
5cSt MIL-PRF-23699G
O-156 (STD)
O-154 (HTS)
Figure 1.3.2 - Recommended engine oil types
Reference : Service Bulletin P & W C. No. 14001 at the latest revision
Maximum certificated weights
Ramp : 7430 lbs (3370 kg)
Takeoff : 7394 lbs (3354 kg)
Landing : 7024 lbs (3186 kg)
Baggage weight
- refer to section 2, paragraph 2.5 for weight and C.G. limits
- refer to section 6 for cargo loading instructions
Standard airplane weights
Standard empty weight : 4583 lbs (2079 kg)
Maximum useful load : 2811 lbs (1275 kg)
PIM - DO NOT USE FOR FLIGHT OPERATIONS
