Daher TBM 930 - Page 400

Pilot's Operating Handbook
Section 5
Performance
Edition 1 - January 15, 2018
Rev. 3
Page 5.10.8
MXCL - Time, consumption and climb distance
(IA
S = 170 KIAS / M 0.40)
Conditions :
- ISA + 20°C
- Maximum climb power
- Landing gear and flaps UP
- IAS = 170 KIAS / M 0.40 - BLEED switch on AUTO
●NOTE ● : Time, consumption and distance from the 50 ft
If BLEED HI msg ON, reduce TRQ by 5 %. This TRQ reduction will result
in :
- Time to climb increased by up to 15 %
- Climb distance increased by up to 16 %
- Fuel consumption increased by up to 12 %
Pressure
altitude
(ft)
Weight
5794 lbs (2628 kg)
Weight
6579 lbs (2984 kg)
Weight
7394 lbs (3354 kg)
Time
(min. s)
Consump.
Dist.
(NM)
Time
(min. s)
Consump.
Dist.
(NM)
Time
(min. s)
Consump.
Dist.
(NM)
l kg USG l kg USG l kg USG
SL
00.00 0 0 0 0 00.00 0 0 0 0 00.00 0 0 0 0
2000
00:45 5 4 1.3 3 01:00 6 4 1.5 3 01:15 7 5 1.7 3
4000
01:45 10 8 2.6 5 02:00 11 9 3.0 6 02:30 13 10 3.5 7
6000
02:45 14 11 3.8 8 03:00 17 13 4.5 9 03:30 20 15 5.2 11
8000
03:30 19 15 5.1 11 04:15 22 18 5.9 13 05:00 26 20 6.9 15
10000
04:30 24 19 6.3 14 05:15 28 22 7.4 17 06:15 33 26 8.6 19
12000
05:30 29 22 7.5 18 06:30 33 26 8.8 21 07:30 39 31 10.3 24
14000
06:30 33 26 8.8 21 07:30 39 31 10.3 25 09:00 46 36 12.0 29
16000
07:30 38 30 10.1 25 08:45 45 35 11.8 29 10:15 52 41 13.8 34
18000
08:30 43 34 11.3 29 10:00 50 40 13.3 34 11:45 59 46 15.6 40
20000
09:45 48 38 12.7 33 11:30 56 44 14.8 39 13:15 66 52 17.4 46
22000
11:00 53 42 14.1 38 13:00 63 49 16.5 45 15:15 74 58 19.5 53
24000
12:30 59 46 15.6 45 14:45 70 55 18.4 53 17:15 82 64 21.7 62
26000
13:45 64 50 17.0 51 16:30 76 60 20.1 60 19:30 90 71 23.8 72
28000
15:30 70 55 18.4 57 18:15 83 65 21.9 68 22:00 99 77 26.1 82
30000
17:15 75 59 19.8 64 20:30 90 70 23.7 77 25:00 108 85 28.5 94
31000
18:00 78 61 20.6 68 21:45 93 73 24.7 82 26:30 113 89 29.8 101
Figure 5.10.8 - MXCL - Time, consumption and climb distance
(IAS = 170 KIAS / M 0.40) / ISA + 20°C
PIM - DO NOT USE FOR FLIGHT OPERATIONS
