Pilot's Operating Handbook
Section 7
Description
Edition 1 - January 15, 2018
Rev. 4
Page 7.3.12
>> Up to S/N 1159
Figure 7.3.5 (1/2) - Right instrument panel
1) PFD 2
2) DISPLAY BACKUP push-button
3) Right station control wheel tube
4) Crew music
5) Adjustable air outlet
6) Right station reception-micro jacks
7) Hourmeter
8) R. H. station rudder pedals adjusting handle
9) Circuit breakers panel postlight
10) Cigar lighter and two USB servicing plugs
11) Cabin emergency air control (EMERGENCY RAM AIR control knob)
12) Static source selector
13) COM 2 (Stand-by / active)
14) Stormscope clear
15) Transponder Ident sequence
16) Chronometer management
17) Paper clip
18) CWS
19) AP / TRIM DISC push-button
20) Push To Talk button (PTT)
21) Pitch & Yaw trim setting management
