Pilot's Operating Handbook
Section 7
Description
Edition 1 - January 15, 2018
Rev. 5
Page 7.9.13
Cabin
override
Setting the switch to the PILOT position disables TEMP and FAN speed selectors in
the cabin area.
The PILOT position also distributes warm air equally to the cockpit and cabin.
Only the cockpit TEMP and FAN selectors inputs are used by the GASC for air
temperature management.
Air temperature
expectations
Cockpit panel selection Cabin panel selection
Cockpit
area
Warm
Cabin
area
/
Results
Mixed Bleed Air Circuit :
Warm air is distributed equally to both the cockpit and cabin. The temperature is selected by the
cockpit TEMP selector.
Cold Air Circuit :
Not active, as the cockpit TEMP selector is set in the red zone and the cabin TEMP selector is
inhibited.
Cockpit FAN : select 0. Selecting a FAN speed will reduce cabin air temperature.
