Pilot's Operating Handbook
Section 7
Description
Edition 1 - January 15, 2018
Rev. 3
Page 7.9.18
Figure 7.9.2 (2/3) - GAS items list and abbreviations
24) Demisting microswitch
25) Hot air distributor (HAD)
26) Cabin inlet temperature sensor (ITS)
27) Cabin bleed temperature switch (BTSW)
28) Mixing ejector (MIXEJ)
29) Check valve
30) MFD unit
31) Ground safety microswitch
32) Differential pressure switch
33) By-pass valve (BPV)
34) Cabin altitude alarm switch
35) Emergency air supply system
(EMERGENCY RAM AIR)
36) Main heat exchanger (MHX)
37) Ground fan (GF)
38) Flow control shut off valve (FCSOV)
39) Bleed differential pressure sensor (BDPS)
40) Compressor
41) Shut-off valve (SOV)
42) Overheat thermal switch (OTSW)
43) Non return valve (NRV)
44) Intermediate port pressure sensor (IPPS)
45) Cabin pressure sensor
