Pilot's Operating Handbook
Section 7
Description
Edition 1 - January 15, 2018
Rev. 5
Page 7.11.4
Figure 7.11.1 (1/2) - Air data system
1) Pitot L
2) Dynamic system drain
3) Standby instrument
4) ADC 1
5) ADC 2
6) Forward pressure bulkhead
7) Static system drain
8) Static system drain
9) Static system drain
10) Alternate static system drain
11) Static source switching valve (Normal / Alternate)
12) Instrument panel
13) Dynamic system drain
14) Pitot R
15) Rear pressure bulkhead
16) Static port
17) Alternate static port
18) Static port
