Pilot's Operating Handbook
Section 8
Handling, servicing and maintenance
Edition 1 - January 15, 2018
Rev. 4
Page 8.9.2
b) Unlock backrest using backrest tilting handle (6) and fold it
forward.
● NOTE ●
For the R.H. rear seat, backrest tilting handle is located behind backrest.
●
c) Unlock seat using seat tilting handle (1) and tilt it forward.
>> Airplane with seats heaters system (Post-MOD70-0588-25)
▲ CAUTION ▲
Make sure to disconnect the seat heating system before the removal of
the seat to prevent harness damage.
▲
d) Disconnect heating system harness, and clip the loose
connector to the holder located on the seat structure.
>> All
e) Clear the carpet from under the seat to facilitate moving in rails.
>> Airplane with seats heaters system (Post-MOD70-0588-25)
f) Open the floor hatch and clip the second loose connector to the
holder located under floor panel. Close the floor hatch.
>> All
g) Hold the seat in tilted position and unscrew quick links (7) of
strap (9) located under L.H. seatpan.
● NOTE ●
This operation is specific to L.H. seat.
●
h) Pull up and hold L.H. and R.H. rings (2), and turn knobs (8) by 90°
in order to release and keep locks (3) in up position.
i) Move the seat in the rails to line up pads (4) with rail (5) apertures.
j) Remove the seat.
● NOTE ●
Ensure proper storage of strap (9) with L.H. rear seat to avoid loosing part.
●
