Daher TBM 930 - Page 759

Pilot's Operating Handbook
List of equipment
Edition 1 - January 15, 2018
Rev. 3
Page 36
S/
R/
A/
O
A
rm
in.
(m)
Weight
per unit
lb
(kg)
Required (R) or Standard (S) or Optional (A or O)
equipment
Item
OPT70
or
MOD70
34-53 - Transponder
A 0475-34A Transponder # 1 GTX 33D - Mode S with antenna
diversity and extended squitter
3.39
(1.54)
147.68
(3.751)
+ Antenna KA 61 (under fuselage) 0.40
(0.18)
150.08
(3.812)
+ Antenna KA 61 (above fuselage) 0.40
(0.18)
193.22
(4.908)
S 0475-34B Transponder # 1 GTX 33 - Mode S without antenna
diversity and with extended squitter
3.11
(1.41)
147.68
(3.751)
+ Antenna KA 61 0.40
(0.18)
193.22
(4.908)
A 0475-34C Transponder # 2 GTX 33 - Mode S with antenna
diversity and extended squitter
3.11
(1.41)
147.68
(3.751)
+ Antenna KA 61 (under fuselage) 0.40
(0.18)
193.22
(4.908)
+ Antenna KA 61 (above fuselage) 0.40
(0.18)
193.22
(4.908)
S 0542-34A Transponder # 1 GTX 345R - full Mode S enhanced
surveillance capability, without antenna diversity,
with extended squitter and ADS-B IN acquisition
(with ethernet connection)
2.90
(1.32)
147.20
(3.738)
+ Antenna KA 61 0.40
(0.18)
150.08
(3.812)
O 0542-34B Transponder # 2 GTX 345R - full Mode S enhanced
surveillance capability, without antenna diversity,
with extended squitter and ADS-B IN acquisition
(without ethernet connection)
2.90
(1.32)
147.20
(3.738)
+ Antenna KA 61 0.40
(0.18)
150.08
(3.812)
PIM - DO NOT USE FOR FLIGHT OPERATIONS
