Pilot's Operating Handbook

Section 2

Limitations

EASA Approved

Edition 1 - January 15, 2018

Rev. 2

Page 2.9.5

(11) Under R.H. control wheel

(12) On nose gear door

(13) On nose gear leg

NOSE LANDING GEAR

TIRE PRESSURE : 6,5 bar

94 psi

PIM - DO NOT USE FOR FLIGHT OPERATIONS
