Dahua L Series User Manual

87
The NVR52-4KS2 series rear panel is shown as below. See Figure 2-35.
Figure 2-35
The NVR52-8P-4KS2 series rear panel is shown as below. See Figure 2-36.
Figure 2-36
The NVR52-16P-4KS2 series rear panel is shown as below. See Figure 2-37.
Figure 2-37
The NVR5224-24P-4KS2 series rear panel is shown as below. See Figure 2-38.
Figure 2-38
The NVR52-16P-4KS2E series rear panel is shown as below. See Figure 2-39.
Figure 2-39
Please refer to the following sheet for detailed information.
Icon
Port Name
Function
Network port
10M/100M/1000Mbps self-adaptive Ethernet port.
Connect to the network cable.
