88
High Definition
Media Interface
High definition audio and video signal output port. It
transmits uncompressed high definition video and
multiple-channel data to the HDMI port of the display
device. HDMI version is 1.4.
USB3.0 port. Connect to mouse, USB storage device,
USB burner and etc.
It is for general COM debug to configure IP address or
transfer transparent COM data.
VGA video output port. Output analog video signal. It can
connect to the monitor to view analog video.
Bidirectional talk input port. It is to receive the analog
audio signal output from the devices such as
microphone, pickup.
Audio output port. It is to output the analog audio signal
to the devices such as the sound box.
Bidirectional talk output.
Audio output on 1-window video monitor.
Audio output on 1-window video playback.
There are two groups. The first group is from port 1
to port 4; the second group is from port 5 to port 8.
They are to receive the signal from the external
alarm source. There are two types; NO (normal
open)/NC (normal close).
When your alarm input device is using external
power, please make sure the device and the NVR
have the same ground.
3 groups of alarm output ports. (Group 1:port NO1～
C1,Group 2:port NO2 ～ C2,Group 3:port NO3～
C3） ).Output alarm signal to the alarm device.
Please make sure there is power to the external
alarm device.
NO: Normal open alarm output port.
C:Alarm output public end.
RS-485
communication
port
RS485_A port. It is the cable A. You can connect to the
control devices such as speed dome PTZ.
RS485_B.It is the cable B. You can connect to the
control devices such as speed dome PTZ.
