Dahua L Series User Manual

159
Figure 4-33
Step 2 Select a channel to set schedule snapshot.
Step 3 Set snapshot type as schedule. Refer to chapter 4.2.5.3 Snapshot for detailed information.
Step 4 Check the box to set alarm type. See Figure 4-34.
Figure 4-34
Note
 When the record type is MD (motion detect), alarm, MD&Alarm, IVS and POS, please enable
the channel snapshot function when corresponding alarm occurs. For example, when the
alarm type is MD, from main menu->Setting->Event->Video Detect->Motion Detect, please
select the snapshot channel and enable snapshot function. See Figure 4-35.
 When the snapshot type is MD (motion detect), alarm, MD&Alarm, IVS, refer to chapter 4.7.1
Video detect, chapter 4.7.9 Alarm Settings, chapter 4.7.3 IVS and chapter 4.7.12 POS.
