Dahua L Series

User's Manual
343
The UPnP interface is displayed. See Figure 4-228.Figure 4-228
Figure 4-229
Step 2 Configure the settings for the UPnP parameters. See Table 4-73.
Table 4-73
Parameter Description
Port Mapping Enable the UPnP function.
Status
Indicates the status of UPnP function.
●
Offline: Failed.
●
Online: Succeeded.
LAN IP
Enter IP address of router on the LAN.
After mapping succeeded, the system obtains IP address automatically without
performing any configurations.
