Supervisions
The drive monitors whether certain user selectable variables
are within the user-dened limits. The user may set limits for
speed, current etc. The supervision status can be indicated
through relay or digital output.
The supervision function outputs can be used for triggering
some drive functionality (start/stop, sleep, pump cleaning).
The supervision functions operate on a 2 ms time level.
Settings
Parameter group Group 32: Supervision
Table 16: Supervisions Diagnostics
Parameter Lock
The user can prevent parameter adjustment by activating the
parameter lock.
Settings
Parameters 1602 PARAMETER LOCK and 1603 PASS CODE,
page 46
Energy Optimizer
Energy optimizer optimizes the ux so that the total energy
consumption and motor noise level are reduced when the drive
operates below the nominal load. The total efciency (motor
and drive) can be improved by 1…10% depending on load
torque and speed.
Energy saving tools calculate energy saved in kWh and MWh,
energy saved in local currency as well as reduction in CO
2
emission, all compared to the situation when the pump is
connected directly to the supply.
Table 17: Energy Optimizer Settings
Table 18: Energy Optimizer Diagnostics
Actual Signal Additional Information
1001/1002
EXT1/EXT2 start/stop according to
supervision functions
140 Supervision status through RO 1
1402/1403/1410
Supervision status through RO 2…4.
With option MREL-01 only.
1805 Supervision status through DO
4022/4122
Sleep start according to supervision
functions
4601
Pump clean trigger according to
supervision functions
Parameter Additional Information
Group 45: Energy Savings Energy saving settings
Actual Signal Additional Information
0174/0175 Energy saved in kWh/Mwh
0176/0177 Energy saved in local currency
0178 Reduction in CO
2
emi
program feaTures
www.DaikinApplied.com 29 OM 1190-1 • MD4 VFD
