Daikin ACS320 - Group 03: Actual Signals

Code Description (continuation of Table 23) Range Resolution Default S
0177 SAVED AMOUNT 2 —
1 = 1000
(Currency)
—
Energy saved in local currency in thousand currency units. Eg value 5 means 5000 currency units. See parameter 0176 SAVED AMOUNT 1.
Local energy price is set with parameter 4502 ENERGY PRICE. Can be reset with parameter 4509 ENERGY RESET (resets all energy calculators at the same time).
See Group 45 ENERGY SAVING, page 66.
0178 SAVED CO
2
— 1 = 0.1 tn —
Reduction on carbon dioxide emissions in tn. CO
2
conversion factor is set with parameter 4507 CO
2
CONV FACTOR. Can be reset with parameter 4509 ENERGY RESET
(resets all energy calculators at the same time). See Group 45 ENERGY SAVING, page 66.
Group 03: Actual Signals
This group monitors eldbus communications.
Table 24: Group 03: Actual Signals
Code Description Range Resolution Default S
0301 FB CMD WORD 1 — — —
Read-only copy of the Fieldbus Command Word 1.
• The eldbus command is the principal means for controlling the drive from a eldbus controller. The command consists of two Command Words. Bit-coded instructions in the
Command Words switch the drive between states.
• To control the drive, using the Command Words, an external location (EXT1 or EXT2) must be active and set to COMM. (See parameters 1001 and 1002.)
• The control panel displays the word in hex. For example, all zeros and a 1 in Bit 0 displays as 0001. All zeros and a 1 in BIt 15 displays as 8000.
Bit # 0301, fb cmd word 1 0302, fb cmd word 2 Bit # 0301, fb cmd word 1 0302, fb cmd word 2
0 STOP FBLOCAL_CTL 8 STPMODE_EM Reserved
1 START FBLOCAL_REF 9 STPMODE_C Reserved
2 REVERSE START_DISABLE1 10 RAMP_2 Reserved
3 LOCAL START_DISABLE2 11 RAMP_OUT_0 REF_CONST
4 RESET Reserved 12 RAMP_HOLD REF_AVE
5 EXT2 Reserved 13 RAMP_IN_0 LINK_ON
6 RUN_DISABLE Reserved 14 RREQ_LOCALLOC REQ_STARTINH
7 STPMODE_R Reserved 15 TORQLIM2 OFF_INTERLOCK
0302 FB CMD WORD 2 — — —
Read-only copy of the Fieldbus Command Word 2.
• See parameter 0301, page 35.
0303 FB STS WORD 1 — 1 - hex
Read-only copy of the Status Word 1.
• The drive sends status information to the eldbus controller. The status consists of two Status Words.
Bit # 0303, sts cmd word 1 0304, fb sts word 2 Bit # 0303, sts cmd word 1 0304, fb sts word 2
0 READY ALARM 8 LIMIT Reserved
1 ENABLED REQ_MAINT 9 SUPERVISION Reserved
2 STARTED DIRLOCK 10 REV_REF REQ_CTL
3 RUNNING LOCALLOCK 11 REV_ACT REQ_REF1
4 ZERO_SPEED CTL_MODE 12 PANEL_LOCAL REQ_REF2
5 ACCELERATE Reserved 13 FIELDBUS_LOCAL REQ_REF2EXT
6 DECELERATE Reserved 14 EXT2_ACT ACK_STARTINH
7 AT_SETPOINT Reserved 15 FAULT ACK_ OFF_ILCK
0304 FB STS WORD 2 — 1 - hex
Read-only copy of the Status Word 2.
• See parameter 0303, page 35.
0305 FAULT WORD 1 — 1 0000 hex
Read-only copy of the Fault Word 1.
• When a fault is active, the corresponding bit for the active fault is set in the Fault Words.
• Each fault has a dedicated bit allocated within Fault Words.
• See Fault Tracing, page 90 for a description of the faults.
The control panel displays the word in hex. For example, all zeros and a 1 in Bit 0 displays a 0001. All zeros and a 1 in Bit 15 displays as 8000.
Bit # 0305,fault word 1 0306 fault word 2 0307 fault word 3 Bit # 0305, fault word 1 0306, fault word 2 0307, fault word 3
0 OVERCURRENT UNDERLOAD EFB 1 8 MOT OVERTEMP Reserved Reserved
1 DC OVERVOLT THERM FAIL EFB 2 9 PANEL LOSS DRIVE ID Reserved
2 DEV OVERTEMP OPEX LINK EFB 3 10 ID RUN FAIL CONFIG FILE System Error
3 SHORT CIRC OPEX PWR Incompatible software type 11 MOTOR STALL SERIAL 1 ERR System Error
4 Reserved CURR MEAS Reserved 12 Reserved EFB CON FILE System Error
5 DC UNDERVOLT SUPPLY PHASE Reserved 13 EXT FLT 1 FORCE TRIP System Error
6 AI1 LOSS ENCODER ERROR Reserved 14 EXT FLT 2 MOTOR PHASE Hardware Error
7 AI2 LOSS OVERSPEED Reserved 15 EARTH FAULT OUTPUT WIRING Param. Setting Fault
0306 FAULT WORD 2 - 1 0000 hex
A16-bit data word. For the possible causes and remedies and eldbus equivalents, see Fault Tracing, page 90.
Bit # Bit # Bit #
0 Reserved 6 Reserved 11 SERIAL 1 ERR
1 THERM FAIL 7 OVERSPEED 12 EFB CON FILE
2...3 Reserved 8 Reserved 13 FORCE TRIP
4 CURR MEAS 9 DRIVE ID 14 MOTOR PHASE
5 SUPPLY PHASE 10 CONFIG FILE 15 OUTP WIRING
