Group 42: External PID
This group denes the parameters used for the second PID controller (PID2) of ACS320. The operation of parameters
4201…4221 is analogous with Process PID set 1 (PID1) parameters 4001…4021.
Table 44: Group 42: External PID
Code Description Range Resolution Default S
4201
...
4221
4202 is integration time and factory set. Typical values are shown in Table 74 on page 109.
Group 45: Energy Savings
This group denes the set-up for calculation and optimization of energy savings.
Table 45: Group 45: Energy Savings
Code Description Range Resolution Default S
4501 ENERGY OPTIMIZER OFF
Enables or disables the energy optimizer, which optimizes the ux so that the total energy consumption and motor noise level are reduced when the drive
operates below the nominal load. The total efciency (motor and drive) can be improved by 1…10% depending on load torque and speed.
OFF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0
Disabled
ON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Enabled
4502 ENERGY PRICE
0.00…
655.35
1 = 0.1
(Currency)
0.00
(Currency)
Price of energy per kWh. Used for reference when energy savings are calculated.
See parameters 0174 SAVED KWH, 0175 SAVED MWH, 0176 SAVED AMOUNT 1, 0177 SAVED AMOUNT 2 and 0178 SAVED CO
2
.
4507 CO
2
CONV FACTOR
0.0…
655.35
tn/MWh
1 = 0.1
tn/MWh
0.5 tn/MWh
Conversion factor used for multiplying the saved energy in MWh to calculate the value of parameter 0178 SAVED CO
2
.
4508 PUMP POWER
0.0…
1000.0%
1 = 0.1% 100.0%
Pump power when connected directly to supply. Used for reference when energy savings are calculated.
See parameters 0174 SAVED KWH, 0175 SAVED MWH, 0176 SAVED AMOUNT 1, 0177 SAVED AMOUNT 2 and 0178 SAVED CO
2
.
4509 ENERGY RESET DONE
Resets energy calculators 0174 SAVED KWH, 0175 SAVED MWH, 0176 SAVED AMOUNT 1, 0177 SAVED AMOUNT 2 and 0178 SAVED CO
2
.
DONE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0
Reset not requested (normal operation).
RESET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Reset energy counters, The value reverts automatically to DONE
