Analog Value Object Instance Summary
The following table summarizes the Analog Value Objects supported:
Table 65: Analog Value Object Instance Summary
Instance
ID
Object Name Description Units
Present Value
Access Type
AV0 OUTPUT SPEED This object indicates the calculated motor speed in RPM. The corresponding drive parameter is 0102. RPM R
AV1 OUTPUT FREQ
This object indicates the output frequency applied to the motor in Hz. The corresponding drive
parameter is 0103.
Hertz R
AV2 DC BUS VOLT This object indicates the drive’s DC bus voltage level. The corresponding drive parameter is 0107. Volts R
AV3 OUTPUT VOLT
This object indicates the AC output voltage applied to the motor. The corresponding drive parameter
is 0109.
Volts R
AV4 CURRENT This object indicates the measured output current. The corresponding drive parameter is 0104. Amps R
AV5 TORQUE
This object indicates the calculated motor output torque as a percentage of nominal torque. The
corresponding drive parameter is 0105.
Percent R
AV6 POWER This object indicates the measured output power in kW. The corresponding drive parameter is 0106. Kilowatts R
AV7 DRIVE TEMP
This object indicates the measured heatsink temperature in °C. The corresponding drive parameter is
0110.
°C R
AV8 KWH (R)
This object indicates, in kW hours, the drive’s accumulated energy usage since the last reset. The
value can be reset to zero. The corresponding drive parameter is 0115.
kWh W
AV9 KWH (NR) This object indicates the drive’s accumulated energy usage in kW hours. The value cannot be reset. kWh R
AV10 PRC PID FBCK This object is the Process PID feedback signal. The corresponding drive parameter is 0130. Percent R
AV11 PRC PID DEV
This object is the Process PID output signal’s deviation from its setpoint. The corresponding drive
parameter is 0132.
Percent R
AV12 EXT PID FBCK This object is the External PID feedback signal. The corresponding drive parameter is 0131. Percent R
AV13 EXT PID DEV
This object is the External PID output signal’s deviation from its setpoint. The corresponding drive
parameter is 0133.
Percent R
AV14 RUN TIME (R)
This object indicates, in hours, the drive’s accumulated run time since the last reset. The value can be
reset to zero. The corresponding drive parameter is 0114.
Hours W
AV15 MOTOR TEMP
This object indicates the drive’s motor temperature, as set up in parameter Group 35. The
corresponding drive parameter is 0145.
°C R
AV16 INPUT REF 1 This object sets Input Reference 1. Control requires parameter 1103 value = COMM. Percent C
AV17 INPUT REF 2
This object sets either: Input Reference 2. Control requires parameter 1106 value = COMM. Process
PID setpoint. Control requires parameter 1106 value = PID1 OUT and parameter 4010 value =
COMM.
Percent C
AV18 LAST FLT
This object indicates the most recent fault entered in the drive’s fault log. The corresponding drive
parameter is 0401.
None R
AV19 PREV FLT 1
This object indicates the second most recent fault entered in the drive’s fault log. The corresponding
drive parameter is 0412.
None R
AV20 PREV FLT 2
This object indicates the third most recent fault entered in the drive’s fault log. The corresponding drive
parameter is 0413.
None R
AV21 AO 1 ACT This object indicates Analog Output 1’s level. The corresponding drive parameter is 0124. Milliamps R
AV23 ACCEL1 TIME This object sets the Ramp1 acceleration time. The corresponding drive parameter is 2202. Seconds W
AV24 DECEL1 TIME This object sets the Ramp1 deceleration time. The corresponding drive parameter is 2203. Seconds W
AV25 MBOX PARAM
This object denes the parameter to be read or written to by the mailbox function. See BV15 and
BV16.
None W
AV26 MBOX DATA
This object holds the mailbox function’s parameter value – a value that was read, or is to be written.
See BV15 and BV16.
None W
AV27 EXT PID STPT
This object sets the External PID controller setpoint. The corresponding drive parameter is 4211.
Control requires parameter 4210, PID SETPOINT SEL, value = 19 (INTERNAL).
Percent C
NOTE: For Present Value Access Types, R = Read-only,W = Writeable, C = Commandable.
Commandable values support priority arrays & relinquish defaults.
