Alarms Generated by the Basic Control Panel
Table 69: Alarms Generated by the Basic Control Panel
The Basic Control Panel indicates Control Panel alarms with a code, A5xxx.
ALARM
CODE
CAUSE WHAT TO DO
5001 Drive is not responding. Check panel connection.
5002 Incompatible communication prole Contact your local Daikin representative.
5010 Corrupted panel parameter backup le Retry parameter upload. Retry parameter download.
5011 Drive is controlled from another source. Change drive control to local control mode.
5012 Direction of rotation is locked. Enable change of direction. See parameter 1003 DIRECTION, page 38.
5013 Panel control is disabled because start inhibit is active.
Start from the panel is not possible. Reset the emergency stop command
or remove the 3-wire stop command before starting from the panel. See
parameters 1001 EXT1 COMMANDS, 1002 EXT2 COMMANDS and 2109
EMERG STOP SEL.
5014 Panel control is disabled because of drive fault. Reset drive fault and retry.
5015 Panel control is disabled because local control mode lock is active.
Deactivate local control mode lock and retry. See parameter 1606 LOCAL
LOCK, page 46.
5018 Parameter default value is not found. Contact your local Daikin representative.
5019 Writing non-zero parameter value is prohibited. Only parameter reset is allowed.
5020
Parameter or parameter group does not exist or parameter value is
inconsistent.
Contact your local Daikin representative.
5021 Parameter or parameter group is hidden. Contact your local Daikin representative.
5022 Parameter is write protected. Parameter value is read-only and cannot be changed.
5023 Parameter change is not allowed, when drive is running. Stop drive and change parameter value.
5024 Drive is executing task. Wait until task is completed.
5025 Software is being uploaded or downloaded. Wait until upload/download is complete.
5026 Value is at or below minimum limit. Contact your local Daikin representative.
5027 Value is at or above maximum limit. Contact your local Daikin representative.
5028 Invalid value Contact your local Daikin representative.
5029 Memory is not ready. Retry.
5030 Invalid request Contact your local Daikin representative.
5031 Drive is not ready for operation, eg due to low DC voltage. Check input power supply.
5032 Parameter error Contact your local Daikin representative.
5040
Parameter download error. Selected parameter set is not in current
parameter backup le.
Perform upload function before download.
5041 Parameter backup le does not t into memory. Contact your local Daikin representative.
5042
Parameter download error. Selected parameter set is not in current
parameter backup le.
Perform upload function before download.
5043 No start inhibit —
5044 Parameter backup le restoring error Check that le is compatible with drive.
5050 Parameter upload aborted Retry parameter upload.
5051 File error Contact your local Daikin representative.
5052 Parameter upload has failed. Retry parameter upload.
5060 Parameter download aborted Retry parameter download.
5062 Parameter download has failed. Retry parameter download.
5070 Panel backup memory write error Contact your local Daikin representative.
5071 Panel backup memory read error Contact your local Daikin representative.
5080 Operation is not allowed because drive is not in local control mode. Switch to local control mode.
5081 Operation is not allowed because of active fault. Check cause of fault and reset fault.
5083 Operation is not allowed because parameter lock is on. Check parameter 1602 PARAMETER LOCK setting.
5084 Operation is not allowed because drive is performing task. Wait until task is completed and retry.
5085 Parameter download from source to destination drive has failed.
Check that source and destination drive types are same, i.e. ACS320. See the
type designation label of the drive.
5086 Parameter download from source to destination drive has failed.
Check that source and destination drive type designations are the same. See
type designation labels of the drives.
5087
Parameter download from source to destination drive has failed because
parameter sets are incompatible.
Check that source and destination drive information are same. See parameters
in Group 33: Information, page 56.
5088 Operation has failed because of drive memory error. Contact your local Daikin representative.
5089 Download has failed because of CRC error. Contact your local Daikin representative.
5090 Download has failed because of data processing error. Contact your local Daikin representative.
5091 Operation has failed because of parameter error. Contact your local Daikin representative.
5092
Parameter download from source to destination drive has failed because
parameter sets are incompatible.
Check that source and destination drive information are same. See parameters
in Group 33: Information, page 56.
faulT TraCIng
