Daikin ACS320 - Fieldbus Equivalent

Fieldbus Equivalent
Example: If 2008 MAXIMUM FREQ (see page 170) is set from
an external control system, an integer value of 1 corresponds
to 0.1 Hz. All the read and sent values are limited to 16 bits
(-32768…32767).
Table 20: Actual Signals in the Short Parameter View
Table 21: Parameters in the Short Parameter View
Actual signals in the short parameter view
No. Name/Value Description FbEq
04 FAULT HISTORY Fault history (read-only). See Group 04: Fault History, page 37.
0401 LAST FAULT Code of the latest fault. 1 = 1
Parameters in the short parameter view
No Name/Value Description Default
1105 REF1 MAX Denes the maximum value for external reference REF1.
E: 50.0 Hz
U: 60.0 Hz
13 ANALOG INPUTS Analog input signal processing. See Group 13: Analog Inputs, page 44.
1301 MINIMUM AI1 Denes the minimum %-value that corresponds to minimum mA/(V) signal for analog input AI1. 1.0%
21 START/STOP Start and stop modes of the motor. See Group 21: Start/Stop, page 49.
2102 STOP FUNCTION Selects the motor stop function. COAST
22 ACCEL/DECEL Acceleration and deceleration times. See Group 22: Accel/Decel, page 50.
2202 ACCELER TIME 1 Denes the acceleration time 1. 5.0 s
2203 DECELER TIME 1 Denes the deceleration time 1. 5.0 s
99 START-UP DATA Language selection. Denition of motor set-up data. See Group 99: Start-Up Data, page 32
9901 LANGUAGE Selects the display language. ENGLISH
9902 APPLIC DEFAULT Selects the application macro Daikin uses "HVAC"
9905 MOTOR NOM VOLT Denes the nominal motor voltage.
230 V (200 V units)
400 V (400 V E units)
460 V (400 V U units)
9906 MOTOR NOM CURR Denes the nominal motor current.
|
2N
9907 MOTOR NOM FREQ Denes the nominal motor frequency.
E: 50.0 Hz
U: 60.0 Hz
9908 MOTOR NOM SPEED Denes the nominal motor speed. Type dependent
9909 MOTOR NOM POWER Denes the nominal motor power. P
N
aCTual sIgnals and parameTers
www.DaikinApplied.com 31 OM 1190-1 • MD4 VFD
