Binary Input Object Instance Summary
The following table summarizes the Binary Input Objects supported:
Table 61: Binary Input Object Instance Summary
Instance ID Object Name Description Active/Inactive Text
Present Value
Access Type
BI0 RO 1 ACT This object indicates the status of Relay Output 1. ON/OFF R
BI1 RO 2 ACT This object indicates the status of Relay Output 2 (requires MREL-01 option). ON/OFF R
BI2 RO 3 ACT This object indicates the status of Relay Output 3 (requires MREL-01 option). ON/OFF R
BI3 RO 4 ACT This object indicates the status of Relay Output 4 (requires MREL-01 option). ON/OFF R
BI6 DI 1 ACT This object indicates the status of Digital Input 1. ON/OFF R
BI7 DI 2 ACT This object indicates the status of Digital Input 2. ON/OFF R
BI8 DI 3 ACT This object indicates the status of Digital Input 3. ON/OFF R
BI9 DI 4 ACT This object indicates the status of Digital Input 4. ON/OFF R
BI10 DI 5 ACT This object indicates the status of Digital Input 5. ON/OFF R
NOTE: For Present Value Access Types, R = Read-only,W = Writeable, C = Commandable.
Commandable values support priority arrays & relinquish defaults.
Binary Output Object Instance Summary
The following table summarizes the Binary Output Objects supported:
Table 62: Binary Output Object Instance Summary
Instance ID Object Name Description Active/Inactive Text
Present Value
Access Type
BO0
RO1
COMMAND
This object controls the output state of Relay 1. This control requires that parameter 1401
value = COMM.
ON/OFF C
BO1
RO2
COMMAND
This object controls the output state of Relay 2. This control requires that parameter 1402
value = COMM (also requires MREL-01 option).
ON/OFF C
BO2
RO3
COMMAND
This object controls the output state of Relay 3. This control requires that parameter 1403
value = COMM (also requires MREL-01 option).
ON/OFF C
BO3
RO4
COMMAND
This object controls the output state of Relay 4. This control requires that parameter 1410
value = COMM (also requires MREL-01 option).
ON/OFF C
NOTE: For Present Value Access Types, R = Read-only,W = Writeable, C = Commandable.
Commandable values support priority arrays & relinquish defaults.
