Group 52: Panel Communication
This group denes the communication settings for the control panel port on the drive. Normally, when using the
supplied control panel, there is no need to change settings in this group. In this group, parameter modications take
effect on the next power-up
Table 46: Group 52: Panel Communication
Code Description Range Resolution Default S
5201 STATION ID 1…247 1 1
Denes the address of the drive.
• Two units with the same address are not allowed on-line.
• Range: 1…247
5202 BAUDRATE
9.6… 115.2
kbits/s
— 9.6 kbits/s
Denes the communication speed of the drive in kbits per second (kbits/s).
9.6
19.2
38.4
57.6
115.2
5203 PARITY 0…3 1 0
Sets the character format to be used with the panel communication.
0 = 8N1 – No parity, one stop bit.
1 = 8N2 – No parity, two stop bits.
2 = 8E1 – Even parity, one stop bit.
3 = 8O1 – Odd parity, one stop bit.
5204 OK MESSAGES 0… 65535 1 —
Contains a count of valid Modbus messages received by the drive.
• During normal operation, this counter is increasing constantly.
5205 PARITY ERRORS 0… 65535 1 —
Contains a count of the characters with a parity error that is received from the eldbus.
For high counts, check:
• Parity settings of devices connected on the eldbus – they must not differ.
• Ambient electro-magnetic noise levels – high noise levels generate errors.
5206 FRAME ERRORS 0… 65535 1 —
Contains a count of the characters with a framing error that the eldbus receives. For high counts, check:
• Communication speed settings of devices connected on the eldbus – they must not differ.
• Ambient electro-magnetic noise levels – high noise levels generate errors.
5207 BUFFER OVERRUNS 0… 65535 1 —
Contains a count of the characters received that cannot be placed in the buffer.
• Longest possible message length for the drive is 128 bytes.
• Received messages exceeding 128 bytes overow the buffer. The excess characters are counted.
5208 CRC ERRORS 0… 65535 1 —
Contains a count of the messages with a CRC error that the drive receives. For high counts, check:
• Ambient electro-magnetic noise levels – high noise levels generate errors.
• CRC calculations for possible errors.
