Code Description (continuation of Table 23) Range Resolution Default S
0132 PID 1 DEVIATION — — —
The difference between the PID 1 controller reference value and actual value.
• Units and scale dened by PID parameters 4006/4106 & 4007/4107.
0133 PID 2 DEVIATION — — —
The difference between the PID 2 controller reference value and actual value.
• Units and scale dened by PID parameters 4206 & 4207.
0134 COMM RO WORD 0...65535 1 0
Free data location that can be written from serial link.
• Used for relay output control.
• See parameter 1401.
0135 COMM VALUE 1
-32768...
+32767
1 0
Free data location that can be written from serial link.
0136 COMM VALUE 2
-32768...
+32767
1 0
Free data location that can be written from serial link.
0137 PROCESS VAR 1 — 1 —
Process variable 1
• Dened by parameters in Group 34: Panel Display / Process Variables, page 57.
0138 PROCESS VAR 2 — 1 —
Process variable 2
• Dened by parameters in Group 34: Panel Display / Process Variables, page 57.
0139 PROCESS VAR 3 — 1 —
Process variable 3
• Dened by parameters in Group 34: Panel Display / Process Variables, page 57.
0140 RUN TIME 0...499.99 kh 0.01 kh 0 kh
The drive’s accumulated running time in thousands of hours (kh).
0141 MWH COUNTER
0...65,535
MWh
1 MWh -
The drive’s accumulated power consumption in megawatt hours. Cannot be reset.
0142 REVOLUTION CNTR 0...9999 1 0
The motor’s accumulated revolutions in millions of revolutions.
0143 DRIVE ON TIME (HI) 0...65535 days 1 day 0
The drive’s accumulated power on time in days.
0144 DRIVE ON TIME (LO)
0...43200
hh:mm:ss
2s 0
The drive’s accumulated power on time in 2 second ticks (30 ticks = 60 seconds).
0145 MOTOR TEMP
-10...200 °C/
0...5000 Ohm /
0...1
1 0
Motor temperature in degrees centigrade / PTC rdsistance in Ohms.
• Applies only if motor temperature sensor is set up. See parameter 3501, page 59.
0158 PID COMM VALUE 1
Data received from eldbus for PID control (PID1 and PID2).
0159 PID COMM VALUE 2
Data received from eldbus for PID control (PID1 and PID2).
0160 DI 1-5 STATUS
Status of digital inputs.
EXAMPLE: 10000 = DI1 is on, DI2...DI5 are off.
0161 PULSE INPUT FREQ 1 = 1 Hz
Value of frequency input in Hz.
0162 RO STATUS 1 = 1
Status of relay output 1.1 = RO is energized, 0 = RO is deenergized.
0163 TO STATUS 1 = 1
Status of transistor output when transistor output is used as a digital output.
0164 TO FREQUENCY 1 = 1 Hz
Transistor output frequency, when transistor output is used as a frequency output.
0173 RO 2-4 STATUS
Status of the relays in the Relay Output Extension Module MREL-0. See MREL-01 Relay Output Extension Module User’s Manual (3AUA0000035974 [English]).
Example: 100 = RO 2 is on, RO3 and RO 4 are off.
0174 SAVED KWH 1 = 0.1 kWh
Energy saved in kWh compared to the energy used when the pump is connected directly to the supply. Can be reset with parameter 4509 ENERGY RESET (resets all energy
calculators at the same time). See Group 45 ENERGY SAVING, page 66.
0175 SAVED MWH 1 = 1 MWh
Energy saved in MWh compared to the energy used when the pump is connected directly to the supply. Can be reset with parameter 4509 ENERGY RESET (resets all energy
calculators at the same time). See Group 45 ENERGY SAVING, page 66.
0176 SAVED AMOUNT 1
1 = 0.1
(Currency)
Energy saved in local currency. To nd out the total saved energy in currency units, add the value of parameter 0177 multiplied by 1000 to the value for parameter 0176.
Example:
0176 SAVED AMOUNT 1 = 123.4
0177 SAVED AMOUNT 2 = 5
Total saved energy = 5 * 1000 + 123.4 = 5123.4 currency units. Local energy price is set with parameter 4502 ENERGY PRICE. Can be reset with parameter 4509 ENERGY RESET
(resets all energy calculators at the same time).
See Group 45 ENERGY SAVING, page 66.
