Code Description (continuation of Table 40) Range Resolution Default S
3406 OUTPUT1 MIN
Depends on
selection
1 —
Sets the minimum value displayed for the rst display parameter.
3407 OUTPUT1 MAX
Depends on
selection
1 —
Sets the maximum value displayed for the rst display parameter.
3408 SIGNAL 2 PARAM 100…199 1 104
Selects the second parameter (by number) displayed on the control panel. See parameter 3401.
3409 SIGNAL 2 MIN
Depends on
selection
1 —
Denes the minimum expected value for the second display parameter. See parameter 3402.
3410 SIGNAL 2 MAX
Depends on
selection
1 —
Denes the maximum expected value for the second display parameter. See parameter 3403.
3411 OUTPUT 2 DSP FORM 0…8 1 —
Denes the decimal point location for the second display parameter. See parameter 3404.
3412 OUTPUT 2 DSP UNIT 0…127 1 1
Selects the units used with the second display parameter. See parameter 3405.
3413 OUTPUT 2 MIN
Depends on
selection
1 —
Sets the minimum value displayed for the second display parameter. See parameter 3406.
3414 OUTPUT 2 MAX
Depends on
selection
1 —
Sets the maximum value displayed for the second display parameter. See parameter 3407.
3415 SIGNAL 3 PARAM 100…199 1 120
Selects the third parameter (by number) displayed on the control panel. See parameter 3401.
3416 SIGNAL 3 MIN
Depends on
selection
1 —
Denes the minimum expected value for the third display parameter. See parameter 3402.
3417 SIGNAL 3 MAX
Depends on
selection
1 —
Denes the maximum expected value for the third display parameter. See parameter 3403.
3418 OUTPUT 3 DSP FORM 0…8 1 1
Denes the decimal point location for the third display parameter. See parameter 3404.
3419 OUTPUT 3 DSP UNIT -128…127 1 11
Selects the units used with the third display parameter. See parameter 3405.
3420 OUTPUT 3 MIN
Depends on
selection
1 —
Sets the minimum value displayed for the third display parameter. See parameter 3406.
3421 OUTPUT 3 MAX
Depends on
selection
1 —
Maximum RPM output of the motor. See parameter 3407. "MA" may be the unit of measure displayed but is
actually RPM.
