Connecting the Linea SWIR GigE Camera Linea SWIR GigE Series Camera

Preventing Operational Faults due to ESD

Install the camera in an ESD (electro-static discharge) safe environment to reduce potential noise.

Note: Using a simple power supply and Ethernet cable will not connect the camera to earth

ground. Ethernet cables have no ground connection and a power supply's 0-voltage return line is

not necessarily connected to earth ground.

The following methods will reduce or prevent ESD problems:

• Method 1: Use a shielded power supply to connect the camera case to earth ground.

• Method 2: Use a shielded Ethernet cable to provide a ground connection from the controlling

computer, to the Linea SWIR GigE.

• Method 3: Mount the camera on a metallic platform with a good connection to earth ground.

• Method 4: Avoid running the Ethernet cable near AC power lines.
