Operational Reference Linea SWIR GigE Series Camera
Off Off No trigger overlap is permitted. (Frame Trigger).
Readout ReadOut Trigger is accepted immediately after the
exposure period (readout). (Line Trigger)
Overlapped exposures must not end before
readout of the previous exposure.
Previous Line previousLine Trigger is accepted (latched) at any time during
the capture of the previous line. (Line Trigger)
Trigger Delay TriggerDelay Only frame triggers can be delayed. Specifies the
delay to apply after receiving the trigger and
before activating trigger event. The delay can be
set in microseconds or in line trigger signals. The
delay can buffer and apply the specified delay to a
maximum of 128 frame trigger pulses
simultaneously. Any additional triggers will be lost
if the trigger delay buffer is full.
1.00
Beginner
Trigger Delay Source triggerDelaySource Sets the event that increments the trigger delay
counter.
1.00
DFNC
Beginner
Internal Clock InternalClock The delay counter increments on each
microsecond tick of the device internal Clock.
Line Trigger Signal lineTriggerSignal The delay counter increments on each pulse
received by the line trigger module. The delay
counter increments even if the pulse is rejected
by the line trigger module.
Line Trigger Input Frequency lineTriggerInputFrequency Current line frequency measured by the camera. 1.00
Beginner
Rotary Encoder Output Mode rotaryEncoderOutputMode Specifies the conditions for the Rotary Encoder
interface to generate a valid Encoder output
signal.
1.00
Expert
DFNC
Position Position On the camera, the "position" behaviour exists,
but the number of counts is small (7-bits / 128
counts). The encoder can reverse for 256 ticks
and then go forward and behave as expected for
"position" style behaviour. If the user exceeds
256 ticks, the count will max out, but will not
reset. When the user starts going forward again,
256 lines will be dropped / ignored and then
resume output.
Motion Motion The triggers are generated for all motion
increments in either direction.
Rotary Encoder Rescaler
Order
rotaryEncoderRescalerOrder Specifies the order that the multiplier and divider
are applied.
1.00
Guru
DFNC
Multiplier Divider multiplierDivider The signal is multiplied before been divided.
Divider Multiplier dividerMultiplier The signal is divided before been multiplied.
Rotary Encoder Multiplier rotaryEncoderMultiplier Specifies a multiplication factor for the rotary
encoder output pulse generator.
1.00
DFNC
Beginner
Rotary Encoder Divider rotaryEncoderDivider Specifies a division factor for the rotary encoder
output pulse generator.
1.00
DFNC
Beginner
Rotary Encoder Direction rotaryEncoderDirection Specifies the phase which defines the encoder
forward direction.
1.00
Expert
DFNC
Clockwise Clockwise Inspection goes forward when the rotary encoder
direction is clockwise (phase B is ahead of phase
A).
Counter Clockwise CounterClockwise Inspection goes forward when the rotary encoder
direction is counter clockwise (phase A is ahead of
phase B).
Rotary Encoder Input A
Source
rotaryEncoderInputASource Rotary Encoder Input A Assignment 1.00
Expert
DFNC
Line 1 Line1 Line1 is assigned to the Rotary Encoder Input A.
