Dalsa Linea SWIR GigE Series User Manual

Linea SWIR GigE Series Camera Operational Reference
•
39
Rotary Encoder Input B
Source
rotaryEncoderInputBSource Selects which input line to assign to the Rotary
Encoder input B (also known as shaft encoder).
Note: that the Line Mode feature must be set to
Input. The list of supported input line sources is
device-specific.
1.00
Expert
DFNC
GND GND Rotary Encoder Input B is not used.
Line 2 Line2 Line2 is assigned to the Rotary Encoder Input B.
Rotary Encoder Source
Activation
rotaryEncoderSrcActivation Specifies the signal edge(s) used to increment the
rotary encoder.
1.00
Expert
DFNC
Rising Edge RisingEdge The rotary encoder uses the rising edge of the
source signal.
Rotary Encoder Multiplier rotaryEncoderMultiplier Specifies a multiplication factor for the rotary
encoder output pulse generator.
1.00
Expert
DFNC
Rotary Encoder Divider rotaryEncoderDivider Specifies a division factor for the rotary encoder
output pulse generator.
1.00
Expert
DFNC
Line Selector LineSelector Selects the physical line (or pin) of the external
device connector to configure.
1.00
Beginner
Line 1
Line 2
Line1
Line2
Index of the physical line and associated I/O
control block to use.
Line Format LineFormat Specify the current electrical format of the
selected physical input or output. Applies to all
physical lines. (RO)
1.00
Expert
Single Ended SingleEnded The line is single ended input for
3.3V/5V/12V/24V or output for 3.3V LVTTL
Open Collector OpenCollector The line is output as open collector.
RS422 RS422 The line accepts or sends RS422 level signals.
Line Mode LineMode Reports if the physical line is an Input or Output
signal. (RO)
1.00
Expert
Input Input The line is an input line.
Output Output The line is an output line.
Input Line Detection Level lineDetectionLevel Specifies the voltage threshold required to
recognize a signal transition on an input line.
1.00
Expert
DFNC
Threshold for 3.3V LVTTL Threshold_for_3V3 A signal below 1.5V will be detected as a Logical
LOW and a signal greater than 1.5V will be
detected as a Logical HIGH on the selected input
line.
Threshold for 5V TTL Threshold_for_5V A signal below 2.5V will be detected as a Logical
LOW and a signal greater than 2.5V will be
detected as a Logical HIGH on the selected input
line.
Threshold for 12V Threshold_for_12V A signal below 5.0V will be detected as a Logical
LOW and a signal greater than 5.0V will be
detected as a Logical HIGH on the selected input
line.
Threshold for 24V Threshold_for_24V A signal below 5.0V will be detected as a Logical
LOW and a signal greater than 5.0V will be
detected as a Logical HIGH on the selected input
line.
Line Status LineStatus Returns the current status of the selected input or
output line. (RO)
1.00
Expert
False / True False / True
Line Inverter LineInverter Controls whether to invert the polarity of the
selected input or output line signal.
1.00
Beginner
False / True False / True
Input Line Debouncing
Period
lineDebouncingPeriod Specifies the minimum delay before an input line
voltage transition is recognized as a signal
transition.
1.00
Beginner
DFNC
