Dalsa Linea SWIR GigE Series User Manual

Linea SWIR GigE Series Camera Operational Reference
•
41
Any Edge AnyEdge Specifies that the trigger is considered valid on
the falling or rising edge of the source signal.
Output Line Pulse Delay outputLinePulseDelay Sets the delay (in µs) before the output line pulse
signal. Applicable for the OutputLineSource
feature. Note, the LineMode feature must be set
to output.
1.00
Beginner
DFNC
Output Line Pulse Duration outputLinePulseDuration Sets the width (duration) of the output line pulse
in microseconds.
1.00
Beginner
DFNC
Output Line Software Latch
Control
outputLineSoftwareLatchControl When Off, the selected output line is set with the
value in Output Line Value. (RO)
1.00
Guru
DFNC
Off Off Output pin state set by outputLineValue.
Output Line Value outputLineValue Sets the output state of the selected Line if the
outputLineSoftwareLatchControl = OFF.
OutputLineSource must be SoftwareControlled. If
the outputLineSoftwareLatchControl = Latch , the
state of the pin will change with the
outputLineSoftwareCmd command.
1.00
Beginner
DFNC
Active Active Sets the Output circuit to close.
Inactive Inactive Sets the Output circuit to open.
Line Status All LineStatusAll Returns the current status of all available line
signals, at time of polling, in a single bitfield. The
order is Line1, Line2, Line3, ... (RO)
1.00
Expert
Output Line Software
Command
outputLineSoftwareCmd Writing a value of 1 in the bit field applies the
Latch value outputLineSoftwareLatchControl and /
or executes the PulseOnSoftwareCmd for any
output line programmed for software control. The
feature outputLineSoftwareCmd can take any
binary value and each bit set to 1 corresponds to
a Icommand for an Output.
Bit-0 is Line 3, Bit-1 is Line 4,
This is applicable to OutputLineSource = Pulse
On: where Software Cmd (for Pulse mode) or
OutputLineSource = SoftwareControlled and
OutputLineSoftwareLatchControl = Latch (for
static states).
1.00
Expert
DFNC
