Page #69 background imageLoading...
Page #69 background image
Linea SWIR GigE Series Camera Operational Reference
67
Cycling Preset Mode Control Feature Description
The following table describes these features along with the view attribute and device version. When
a Device Version number is indicated, it represents the camera software functional group, not a
firmware revision number. As Linea SWIR GigE capabilities evolve the device version will increase,
identifying the supported function package. New features for a major device version release will be
indicated by green text for easy identification.
The Description column will indicate which feature is a member of DALSA’s Features Naming
Convention (denoted by DFNC), versus the GenICam Standard Features Naming Convention (SFNC
not shown).
Display Name Feature & Values Description Device Version
& View
Cycling Preset Mode cyclingPresetMode Sets the Cycling Presets module mode. V1.00
Expert
DFNC
Off Off Disable the Cycling Preset module.
Active Active Enable the Cycling Preset module.
Cycling Preset Count cyclingPresetCount Specifies the number of Presets to use.
V1.00
Expert
DFNC
Cycling Preset
Incremental Source
cyclingPresetIncrementalSource Specifies the source that increments the
currently active cycling preset.
V1.00
Expert
DFNC
Start of Line StartOfLine Increment on start of line event
Start of Frame StartOfFrame Increment on start of frame event
Line 1 Line1 Select Line 1 (and associated IO control block)
as cycling preset incremental source
Line 2 Line2 Select Line 2 (and associated IO control block)
as cycling preset incremental source
Cycling Preset
Incremental Mode
cyclingPresetIncrementalMode Sets the synchronization point after a
increment trigger occur. This is use when the
increment source is an line, counter or timer.
V1.00
Expert
DFNC
Line NextLine The next set will take effect when the next
line acquisition will start.
Frame NextFrame The next set will take effect when the next
line acquisition will start.
Cycling Preset Repeater cyclingPresetRepeater Specifies the required number of cycling
preset increment events (generated by the
Cycling Preset Incremental Source) to
increment the index of the Cycling Preset
Current Active Set.
V1.00
Expert
DFNC
Cycling Preset Reset
Source
cyclingPresetResetSource Specifies the source that resets the currently
active preset. On reset the current preset
index is set to 1.
V1.00
Expert
DFNC
Start of Frame StartOfFrame Reset when a valid frame trigger occurs.
Software Software Use a software command as the reset source.
Cycling Preset Reset Cmd cyclingPresetResetCmd Reset the position of the preset cycling to 1
and the count to 0.
V1.00
Guru
DFNC
Cycling Preset Current
Active Set
cyclingPresetCurrentActiveSet Returns the index of the currently active
cycling preset.
V1.00
Guru
DFNC
Features Activation
Selector
cP_FeaturesActivationSelector Selects the feature to control by the
cP_FeaturesActivationMode feature.
V1.00
Expert
DFNC
Exposure Time ExposureTime The cP_FeaturesActivationMode feature
controls the exposure time.
