68
Operational Reference Linea SWIR GigE Series Camera
Exposure Delay ExposureDelay The cP_FeaturesActivationMode feature
controls the exposure delay.
Gain Gain The cP_FeaturesActivationMode feature
controls the Gain.
Flat Field Correction FlatFieldCorrection The cP_FeaturesActivationMode feature
controls the flat field correction.
Output Lines OutputLineControl The cP_FeaturesActivationMode feature
controls the output lines.
Features Activation Mode cP_FeaturesActivationMode Enables the selected feature to be part of the
cycling. When activating the selected feature,
this will automatically set the corresponding
standard camera feature to read only.
V1.00
Expert
DFNC
Off Off Exclude the selected feature from the cycling.
Active Active Activate the selected feature in the cycling.
Preset Configuration
Selector
cP_PresetConfigurationSelector Selects the cycling preset to configure.
V1.00
Expert
DFNC
Exposure Time cP_ExposureTime Sets the exposure time (in microseconds) for
the selected set.
V1.00
Expert
DFNC
Gain cP_Gain Sets the selected gain as an amplification
factor applied to the image.
V1.00
Expert
DFNC
Flat Field Correction
Current Active Set
cP_flatfieldCorrectionCurrentActiveSet Specifies the current set of Flat Field
coefficients to use.
V1.00
Expert
DFNC
User Flatfield 1 UserFlatfield1 Sets User Flat Field 1 coefficient table as the
current Flat Field.
User Flatfield 2 UserFlatfield2 Sets User Flat Field 2 coefficient table as the
current Flat Field.
User Flatfield 3 UserFlatfield3 Sets User Flat Field 3 coefficient table as the
current Flat Field.
User Flatfield 4 UserFlatfield4 Sets User Flat Field 4 coefficient table as the
current Flat Field.
Line Selector cP_LineSelector Selects which physical line (or pin) of the
external device connector to configure.
V1.00
Expert
DFNC
Line 3 or pin 6 Line2 Index of the physical line and associated
Output control block to use.
Line 4 or pin 8 Line4 Index of the physical line and associated I/O
control block to use.
Output Line Source cP_OutputLineSource Selects which internal signal, or event driven
pulse, or software control state to output on
the selected output line.
V1.00
Expert
DFNC
Off Off Line output is Open.
Software Controlled SoftwareControlled The OutputLineValue feature changes the
state of the output.
Pulse On: Start of
Exposure
PulseOnStartofExposure Generate a pulse on the ExposureStart event.
This option is typically used to trigger a strobe
light.
Output Line Value cP_OutputLineValue Sets the output state of the selected Line if
the outputLineSoftwareLatchControl = OFF.
OutputLineSource must be
SoftwareControlled. If the
outputLineSoftwareLatchControl = Latch , the
state of the pin will change with the
outputLineSoftwareCmd command.
V1.00
Expert
DFNC
Active Active Sets the Output circuit to closed.
Inactive Inactive Sets the Output circuit to open.
Exposure Delay cP_ExposureDelay Sets the exposure delay (in microseconds) for
the selected set.
V1.00
Expert
DFNC
