Dalsa Xtium-CLHS PX8 - ACQ Related Parameters; Table 10: Acquisition Related Parameters

Xtium-CLHS PX8 User's Manual Xtium-CLHS PX8 Reference
•
53
ACQ Related Parameters
Parameter Values
CORACQ_PRM_LABEL Camera Link HS Mono
CORACQ_PRM_EVENT_TYPE CORACQ_VAL_EVENT_TYPE_START_OF_FRAME
CORACQ_VAL_EVENT_TYPE_END_OF_FRAME
CORACQ_VAL_EVENT_TYPE_EXTERNAL_TRIGGER
CORACQ_VAL_EVENT_TYPE_VERTICAL_SYNC
CORACQ_VAL_EVENT_TYPE_FRAME_LOST
CORACQ_VAL_EVENT_TYPE_DATA_OVERFLOW
CORACQ_VAL_EVENT_TYPE_EXTERNAL_TRIGGER_IGNORED
CORACQ_VAL_EVENT_TYPE_EXT_LINE_TRIGGER_TOO_SLOW
CORACQ_VAL_EVENT_TYPE_LINK_ERROR
CORACQ_VAL_EVENT_TYPE_SHAFT_ENCODER_REVERSE_COUNT_OVERFLOW
CORACQ_PRM_EVENT_TYPE_EX CORACQ_VAL_EVENT_TYPE_LINK_LOCK
CORACQ_VAL_EVENT_TYPE_LINK_UNLOCK
CORACQ_VAL_EVENT_TYPE_CAMERA_MISSED_TRIGGER
CORACQ_VAL_EVENT_TYPE_CAMERA_OVERRUN
CORACQ_PRM_SIGNAL_STATUS CORACQ_VAL_SIGNAL_HSYNC_PRESENT
CORACQ_VAL_SIGNAL_VSYNC_PRESENT
CORACQ_VAL_SIGNAL_POWER_PRESENT
CORACQ_VAL_SIGNAL_POCL_ACTIVE
CORACQ_VAL_SIGNAL_LINK_LOCK
CORACQ_VAL_SIGNAL_LANE1_LOCK
CORACQ_VAL_SIGNAL_LANE2_LOCK
CORACQ_VAL_SIGNAL_LANE3_LOCK
CORACQ_VAL_SIGNAL_LANE4_LOCK
CORACQ_VAL_SIGNAL_LANE5_LOCK
CORACQ_VAL_SIGNAL_LANE6_LOCK
CORACQ_VAL_SIGNAL_LANE7_LOCK
CORACQ_PRM_FLAT_FIELD_ENABLE Not Available
CORACQ_PRM_TIME_STAMP Available
CORACQ_CAP_SERIAL_PORT_INDEX Not Available
CORACQ_PRM_IMAGE_FILTER_ENABLE TRUE
FALSE
CORACQ_PRM_IMAGE_FILTER_KERNEL_SIZE CORACQ_VAL_IMAGE_FILTER_KERNEL_SIZE_3x3 (0x4)
CORACQ_PRM_IMAGE_FILTER_SELECT min = 0
max = 1
step = 1
CORACQ_CAP_IMAGE_FILTER_KERNEL_VALUE min = -32768
max = 32767
step = 1
CORACQ_CAP_IMAGE_FILTER_KERNEL_DIVISOR 16384
Table 10: Acquisition Related Parameters
