Sapera Servers and Resources
A Sapera Server is an abstract representation of a physical device like a frame-grabber or camera.
When using the SapAcquisition or SapAcqDevice constructors, the location parameter specifies the
server to use to create the object. Use the Sapera Configuration utility to find the names and
indices of all Sapera servers in your system.
In Sapera LT all frame grabbers are configured using the SapAcquisition class. All CLHS cameras
are GenCP compliant and are configured in Sapera LT using the SapAcqDevice class.
Note: Currently, CLHS cameras do not have their own server, therefore it is available
under the Xtium_CLHS server. For example, in CamExpert the Xtium server displays
both the frame grabber and camera resources.
The following table describes the Xtium-CLHS PX8 board
Servers Resources
Name Type Name Index Description
Xtium-CLHS_PX8_1 Acquisition Camera Link HS 0 CLHS Camera
All GIO General Outputs #1
General Inputs #1
Bidirectional General
I/Os #1
0
1
2
8 General Outputs
4 General Inputs
8 Bidirectional General I/Os
Table 18: Xtium-CLHS PX8 - Servers and Resources
