Xtium-CLHS PX8 User's Manual Xtium-CLHS PX8 Reference
•
49
CORACQ_PRM_LINE_INTEGRATE_METHOD CORACQ_VAL_LINE_INTEGRATE_METHOD_8 (0x80)
CORACQ_VAL_LINE_INTEGRATE_METHOD_9 (0x100)
CORACQ_VAL_LINE_INTEGRATE_METHOD_10 (0x200)
CORACQ_PRM_LINE_TRIGGER_METHOD CORACQ_VAL_LINE_TRIGGER_METHOD_2 (0x2)
CORACQ_PRM_LINE_TRIGGER_DELAY min = 0 nsec
max = 4294967295 nsec
step = 1 nsec
CORACQ_PRM_CHANNELS_ORDER CORACQ_VAL_CHANNELS_ORDER_NORMAL (0x1)
CORACQ_PRM_CAM_LINE_TRIGGER_FREQ_MIN 1 Hz
CORACQ_PRM_CAM_LINE_TRIGGER_FREQ_MAX 16777215 Hz
CORACQ_PRM_CAM_TIME_INTEGRATE_DURATION_MIN 1 µs
CORACQ_PRM_CAM_TIME_INTEGRATE_DURATION_MAX 85899345 µs
CORACQ_PRM_CAM_IO_CONTROL (*)
CORACQ_PRM_DATA_VALID_ENABLE TRUE
FALSE
CORACQ_PRM_BAYER_ALIGNMENT Not available
CORACQ_PRM_CAM_CONTROL_DURING_READOUT CORACQ_VAL_CAM_CONTROL_DURING_READOUT_INVALID (0x0)
CORACQ_VAL_CAM_CONTROL_DURING_READOUT_VALID (0x01)
CORACQ_VAL_CAM_CONTROL_DURING_READOUT_IGNORE (0x2)
CORACQ_PRM_DATA_LANES min = 1 lane, max = 7 lanes, step = 1 lane
CORACQ_PRM_BIT_TRANSFER_RATE 3.125 Gbps
CORACQ_PRM_CLHS_CONFIGURATION CORACQ_VAL_CLHS_CONFIGURATION_CAM_PORT_SLAVE (0x4)
CORACQ_VAL_CLHS_CONFIGURATION_MANUAL_ACQ_START_STOP
(0x8)
Table 8: Camera Related Parameters
VIC Related Parameters
Parameter Values
CORACQ_PRM_CAMSEL CAMSEL_MONO = from 0 to 0
CORACQ_PRM_CROP_LEFT min = 0 pixel
max = 16376 pixel
step = 8 pixel
CORACQ_PRM_CROP_TOP min = 0 line
max = 16777215 line
step = 1 line
CORACQ_PRM_CROP_WIDTH min =32 pixel
max = 16384 pixel
step =8 pixel
CORACQ_PRM_CROP_HEIGHT min = 1 line
max = 16777215 line
step = 1 line
CORACQ_PRM_DECIMATE_METHOD CORACQ_VAL_DECIMATE_DISABLE (0x1)
CORACQ_PRM_LUT_ENABLE Not Available
CORACQ_PRM_LUT_NUMBER Default = 0
CORACQ_PRM_STROBE_ENABLE TRUE
FALSE
CORACQ_PRM_STROBE_METHOD CORACQ_VAL_STROBE_METHOD_1 (0x1)
CORACQ_VAL_STROBE_METHOD_3 (0x4)
CORACQ_VAL_STROBE_METHOD_4 (0x8)
CORACQ_VAL_STROBE_METHOD_5 (0x10)
CORACQ_PRM_STROBE_POLARITY CORACQ_VAL_ACTIVE_LOW (0x1)
CORACQ_VAL_ACTIVE_HIGH (0x2)
CORACQ_PRM_STROBE_DURATION min = 1 µs
max = 85899345 µs
step = 1 µs
CORACQ_PRM_STROBE_DELAY min = 0 µs
max = 85899345 µs
step = 1 µs
CORACQ_PRM_TIME_INTEGRATE_ENABLE TRUE
FALSE
