Xtium-CLHS PX8 Reference Xtium-CLHS PX8 User's Manual
Bidirectional General I/Os: Related Capabilities (for GIO Module #2)
These I/Os are available on connector J5
Capability Values
CORGIO_CAP_IO_COUNT 8 I/Os
CORGIO_CAP_DIR_OUTPUT 0xff
CORGIO_CAP_DIR_TRISTATE 0xff
CORGIO_CAP_EVENT_TYPE Not Available
CORGIO_CAP_READ_ONLY 0x03 (* depends on board syncs reserved for acquisition device)
Table 16: GIO-2 Related Capabilities
Bidirectional General I/Os: Related Parameters (for GIO Module #2)
Parameter Values
CORGIO_PRM_LABEL Bidirectional General I/Os #1
CORGIO_PRM_DEVICE_ID 2
CORGIO_PRM_OUTPUT_TYPE CORGIO_VAL_OUTPUT_TYPE_LVTTL (0x20)
CORGIO_PRM_INPUT_LEVEL CORGIO_VAL_INPUT_LEVEL_LVTTL (0x20)
CORGIO_PRM_CONNECTOR CORGIO_VAL_CONNECTOR_2 (0x2)
Table 17: GIO-2 Related Parameters
