Technical Specifications Xtium-CLHS PX8 User's Manual
D3: Camera Link HS Status LED (as Data Forwarding receiver)
When the Xtium-CLHS PX8 does not have a camera connected but is used as a Data Forwarding
Slave, (i.e. the board receives data on J3 from another Xtium in a separate computer), the LED D3
describes these two additional conditions.
LED Color State Description
Green Flashing Connection not established on input connector J3
Green Constant Link established on input connector J3 and data transfer may
take place.
Table 25: Camera Link HS Status LED: J3 connected to data forwarding output of another Xtium-CLHS PX8
D6: Data Forwarding Status LED
D6 defines the connection status for when the Camera Link HS output J2 is forwarding acquisition
data to another Xtium-CLHS in a separate computer. Note that the Xtium-CLHS PX8 data
forwarding feature is not part of the standard CLHS specifications.
LED Color State Description
Off Constant Connection not established on input connector J3 of the
receiving Xtium-CLHS
Green Constant Link established with the receiving Xtium-CLHS and data
transfer may take place.
Table 26: Data Forwarding Status LED
J2: Data Forwarding Connector
Note: The Data Forwarding connector on the Xtium-CLHS PX8 has the same specifications as
the Camera Link HS camera connector (J3) defined in the AIA document “Specifications of the
Camera Link HS Interface Standard for Digital Cameras and Frame Grabbers” version 1.0 RC5,
©2012 AIA. Typically there is no need to be concerned with the physical pinout of the
connector or cables. Refer to their site www.visiononline.org
for additional information.
