General Outputs #1: Related Parameters (for GIO Module #0)
Parameter Values
CORGIO_PRM_LABEL General Outputs #1
CORGIO_PRM_DEVICE_ID 0
CORGIO_PRM_OUTPUT_TYPE CORGIO_VAL_OUTPUT_TYPE_TTL (0x10)
CORGIO_PRM_CONNECTOR CORGIO_VAL_CONNECTOR_1 (0x1)
Table 13: GIO-0 Related Parameters
General Inputs #1: Related Capabilities (for GIO Module #1)
Inputs available on connector J1 and J4.
Capability Values
CORGIO_CAP_IO_COUNT 4 I/Os
CORGIO_CAP_DIR_OUTPUT 0x0
CORGIO_CAP_DIR_TRISTATE 0x0
CORGIO_CAP_EVENT_TYPE CORGIO_VAL_EVENT_TYPE_RISING_EDGE (0x1)
CORGIO_VAL_EVENT_TYPE_FALLING_EDGE (0x2)
CORGIO_CAP_READ_ONLY 0x03 (* depends on external trigger inputs reserved for acquisition device)
Table 14: GIO-1 Related Capabilities
General Inputs #1: Related Parameters (for GIO Module #1)
Parameter Values
CORGIO_PRM_LABEL General Inputs #1
CORGIO_PRM_DEVICE_ID 1
CORGIO_PRM_INPUT_LEVEL CORGIO_VAL_INPUT_LEVEL_TTL (0x1)
CORGIO_VAL_INPUT_LEVEL_422 (0x2)
CORGIO_VAL_INPUT_LEVEL_24VOLTS (0x8)
CORGIO_VAL_INPUT_LEVEL_12VOLTS (0x40)
CORGIO_PRM_CONNECTOR CORGIO_VAL_CONNECTOR_1 (0x1)
Table 15: GIO-1 Related Parameters
