Technical Specifications Xtium-CLHS PX8 User's Manual
Block Diagram: Connecting External Receivers to the General Outputs
J1: External Signals Connector
(
DH60
-27P)
To External Devices
Xtium-
CL
HS PX8
1
Vcc
Compatible
Receiver
User Signal
Ground
Reserved
26
27
:
:
25 :
24
:
23 :
General Output
422
:
General Output
321
:
19
20
:
:
18
:
17 :
General Input 4
(+)
16 :
General Input
3 (+)15 :
Power Output
(
12
Volts
)
14
:
Ground13
:
General Output 212 :
General Output 1
/ Strobe11 :
Ground10 :
General Input 2 / Trigger 2 (+)9 :
General Input 1
/ Trigger 1 (+)8 :
7 :
Shaft Encoder B (+)6 :
Shaft Encoder B (
-)5 :
Ground
4 :
Shaft Encoder A
(+)3 :
Shaft Encoder A
(-)2 :
Ground
1
:
General Input
1 / Trigger 1 (-)
General Input 4 (-)
General Input 3 (-)
Power Output (5 Volts)
General Input 2 / Trigger 2 (-)
General Output 5
General Output 6
General Output 7
General Output 8
2
Vcc
Compatible
Receiver
3
Vcc
Compatible
Receiver
4
Vcc
Compatible
Receiver
5
Vcc
Compatible
Receiver
6
Vcc
Compatible
Receiver
7
Vcc
Compatible
Receiver
8
Vcc
Compatible
Receiver
Figure 27:Output Signals Connection Diagram
External Receiver Electrical Requirements
 Xtium General Outputs are standard TTL logic levels.
 External receiver circuits must be compatible to TTL signals.
Xtium PX8
Output Level
Description MIN MAX
TTL
Output Voltage High (V
H
)
2.0 V –
Output Voltage Low (V
L
)
– 0.8 V
