Dalsa Xtium-CLHS PX8 - Technical Specifications; Xtium-CLHS PX8 Board Specifications; Table 19: Board Specifications

Xtium-CLHS PX8 User's Manual Technical Specifications
•
59
Technical Specifications
Xtium-CLHS PX8 Board Specifications
Digital Video Input & Controls
Input Type Camera Link HS Specifications Rev 1.0 compliant
Common Pixel Formats Camera Link HS for 8, 10, 12, 14 and 16-bit mono
Scanning Area scan and Line scan
Resolution
note: these are Xtium-
CLHS PX8 maximums,
not Camera Link HS
specifications
Horizontal Minimum:
8 Pixels per lane (8-bits/pixel)
Horizontal Maximum:
8-bits/pixel x 16k Pixels/line
16-bits/pixel x 8k Pixels/line
Vertical Minimum:
1 line
Vertical Maximum:
up to 16,000,000 lines—for area scan sensors
infinite line count—for linescan sensors
Bit Transfer Rate 3.125 Gbps
Image Buffer Available with 512 MB
Bandwidth to Host
System
Approximately 3.4 GB/s (maximum obtained is dependent on firmware
loaded and PC characteristics)
Controls Compliant with Teledyne DALSA Trigger-to-Image Reliability framework
Comprehensive event notifications
Timing control logic for camera triggers and strobe signals
4 opto-coupled general inputs where 2 are shared acquisition trigger inputs
(RS-422/TTL/12V/24V)
Trigger inputs are programmable as active high or low (edge or level
trigger, at maximum input frequency of 100 KHz)
External trigger latency less than 100 nsec
8 TTL general Outputs where 1 is shared as Strobe Output
Quadrature (phase A & B) shaft encoder inputs for external web
synchronization: RS-422 input maximum frequency is 5 MHz
Supports camera Data Forwarding up to 5 additional boards
Supports multi-camera synchronization of 2 to 4 boards
I/O available on a DH60-27P connector (J1)
and on 26-pin SHF-113-01-L-D-RA (J4)
Processing
Dependent on user
loaded firmware
configuration
Output Lookup Table
Contact Teledyne DALSA for availability.
Bayer Mosaic Filter
Contact Teledyne DALSA for availability.
Table 19: Board Specifications
