50
•
Xtium-CLHS PX8 Reference Xtium-CLHS PX8 User's Manual
CORACQ_PRM_TIME_INTEGRATE_DURATION min = 1 µs
max = 85899345 µs
step = 1 µs
CORACQ_PRM_CAM_TRIGGER_ENABLE TRUE
FALSE
CORACQ_PRM_OUTPUT_FORMAT CORACQ_VAL_OUTPUT_FORMAT_MONO8
CORACQ_VAL_OUTPUT_FORMAT_MONO16
CORACQ_PRM_EXT_TRIGGER_ENABLE CORACQ_VAL_EXT_TRIGGER_OFF (0x1)
CORACQ_VAL_EXT_TRIGGER_ON (0x8)
CORACQ_PRM_VIC_NAME Default Camera Link HS Line Scan Mono
CORACQ_PRM_LUT_MAX 0
CORACQ_PRM_EXT_TRIGGER_DETECTION CORACQ_VAL_ACTIVE_LOW (0x1)
CORACQ_VAL_ACTIVE_HIGH (0x2)
CORACQ_VAL_RISING_EDGE (0x4)
CORACQ_VAL_FALLING_EDGE (0x8)
CORACQ_PRM_LUT_FORMAT Default = CORDATA_FORMAT_MONO8
CORACQ_PRM_LINE_INTEGRATE_ENABLE TRUE
FALSE
CORACQ_PRM_LINE_INTEGRATE_DURATION min = 1 nsec
max = 4294967295 nsec
step = 1 nsec
CORACQ_PRM_LINE_TRIGGER_ENABLE TRUE
FALSE
CORACQ_PRM_EXT_FRAME_TRIGGER_ENABLE TRUE
FALSE
CORACQ_PRM_EXT_FRAME_TRIGGER_DETECTION CORACQ_VAL_ACTIVE_LOW (0x1)
CORACQ_VAL_ACTIVE_HIGH (0x2)
CORACQ_VAL_RISING_EDGE (0x4)
CORACQ_VAL_FALLING_EDGE (0x8)
CORACQ_VAL_DOUBLE_PULSE_RISING_EDGE (0x20)
CORACQ_VAL_DOUBLE_PULSE_FALLING_EDGE (0x40)
CORACQ_PRM_EXT_LINE_TRIGGER_ENABLE TRUE
FALSE
CORACQ_PRM_EXT_LINE_TRIGGER_DETECTION CORACQ_VAL_RISING_EDGE (0x4)
CORACQ_VAL_FALLING_EDGE (0x8)
CORACQ_PRM_SNAP_COUNT Not Available
CORACQ_PRM_INT_LINE_TRIGGER_ENABLE TRUE
FALSE
CORACQ_PRM_INT_LINE_TRIGGER_FREQ Default = 5000 Hz
CORACQ_PRM_BIT_ORDERING CORACQ_VAL_BIT_ORDERING_STD (0x1)
CORACQ_PRM_EXT_TRIGGER_LEVEL CORACQ_VAL_LEVEL_TTL (0x1)
CORACQ_VAL_LEVEL_422 (0x2)
CORACQ_VAL_LEVEL_12VOLTS (0x040)
CORACQ_VAL_LEVEL_24VOLTS (0x8)
CORACQ_PRM_STROBE_LEVEL CORACQ_VAL_LEVEL_TTL (0x1)
CORACQ_PRM_EXT_FRAME_TRIGGER_LEVEL CORACQ_VAL_LEVEL_TTL (0x1)
CORACQ_VAL_LEVEL_422 (0x2)
CORACQ_VAL_LEVEL_12VOLTS (0x040)
CORACQ_VAL_LEVEL_24VOLTS (0x8)
CORACQ_PRM_EXT_LINE_TRIGGER_LEVEL CORACQ_VAL_LEVEL_422 (0x2)
CORACQ_PRM_INT_LINE_TRIGGER_FREQ_MIN 8 Hz
CORACQ_PRM_INT_LINE_TRIGGER_FREQ_MAX 500000 Hz
CORACQ_PRM_MASTER_MODE Not available
CORACQ_PRM_SHAFT_ENCODER_DROP min = 0 tick
max = 254 tick
step = 1 tick
CORACQ_PRM_SHAFT_ENCODER_ENABLE TRUE
FALSE
CORACQ_PRM_EXT_TRIGGER_FRAME_COUNT min = 1 frame
max = 262142 frame
step = 1 frame
Note: Infinite not supported
CORACQ_PRM_INT_FRAME_TRIGGER_ENABLE TRUE
FALSE
