Xtium-CLHS PX8 User's Manual Xtium-CLHS PX8 Reference
•
51
CORACQ_PRM_INT_FRAME_TRIGGER_FREQ min = 1 milli-Hz
max = 1000000000 milli-Hz
step = 1 milli-Hz
CORACQ_PRM_STROBE_DELAY_2 Not Available
CORACQ_PRM_FRAME_LENGTH CORACQ_VAL_FRAME_LENGTH_FIX (0x1)
CORACQ_PRM_FLIP CORACQ_VAL_FLIP_OFF (0x00)
CORACQ_VAL_FLIP_HORZ (0x01)
CORACQ_PRM_EXT_TRIGGER_DURATION min = 0 µs
max = 255 µs
step = 1 µs
CORACQ_PRM_TIME_INTEGRATE_DELAY min = 0 µs
max = 85899345 µs
step = 1 µs
CORACQ_PRM_CAM_TRIGGER_DELAY min = 0 µs
max = 85899345 µs
step = 1 µs
CORACQ_PRM_SHAFT_ENCODER_LEVEL CORACQ_VAL_LEVEL_422 (0x2)
CORACQ_PRM_EXT_FRAME_TRIGGER_SOURCE (*) min = 0
max = 5
step = 1
CORACQ_PRM_EXT_LINE_TRIGGER_SOURCE (*) min = 0
max = 5
step = 1
CORACQ_PRM_EXT_TRIGGER_SOURCE (*) min = 0
max = 5
step = 1
CORACQ_PRM_SHAFT_ENCODER_MULTIPLY min = 1
max = 32
step = (2
N
)
CORACQ_PRM_EXT_TRIGGER_DELAY min = 0
max = 16777215
step = 1
CORACQ_PRM_EXT_TRIGGER_DELAY_TIME_BASE CORACQ_VAL_TIME_BASE_LINE_VALID (0x4)
CORACQ_VAL_TIME_BASE_LINE_TRIGGER (0x8)
CORACQ_VAL_TIME_BASE_SHAFT_ENCODER (0x40)
CORACQ_VAL_TIME_BASE_NS (0x80)
CORACQ_PRM_BAYER_DECODER_ENABLE Not Available
CORACQ_PRM_EXT_TRIGGER_IGNORE_DELAY Not Available
CORACQ_PRM_BOARD_SYNC_OUTPUT1_SOURCE (*) min = 0
max = 2
step = 1
CORACQ_PRM_BOARD_SYNC_OUTPUT2_SOURCE (*) min = 0
max = 2
step = 1
CORACQ_PRM_EXT_TRIGGER_SOURCE_STR [0] = Automatic
[1] = External Trigger #1
[2] = External Trigger #2
[3] = Board Sync #1
[4] = Board Sync #2
[5] = Software Trigger
CORACQ_PRM_EXT_LINE_TRIGGER_SOURCE_STR [0] = Automatic
[1] = Shaft Encoder Phase A
[2] = Shaft Encoder Phase B
[3] = Shaft Encoder Phase A & B
[4] = Board Sync #1
[5] = Board Sync #2
CORACQ_PRM_VERTICAL_TIMEOUT_DELAY Not Available
CORACQ_PRM_POCL_ENABLE TRUE
FALSE
CORACQ_PRM_SHAFT_ENCODER_DIRECTION CORACQ_VAL_SHAFT_ENCODER_DIRECTION_IGNORE (0x00)
CORACQ_VAL_SHAFT_ENCODER_DIRECTION_FORWARD (0x01)
CORACQ_VAL_SHAFT_ENCODER_DIRECTION_REVERSE (0x02)
CORACQ_PRM_LINE_TRIGGER_AUTO_DELAY Not Available
CORACQ_PRM_TIME_STAMP_BASE CORACQ_VAL_TIME_BASE_US (0x1)
CORACQ_VAL_TIME_BASE_LINE_VALID (0X4)
CORACQ_VAL_TIME_BASE_LINE_TRIGGER (0X8)
CORACQ_VAL_TIME_BASE_SHAFT_ENCODER (0X40)
CORACQ_PRM_BOARD_SYNC_OUTPUT1_SOURCE_STR [0] = Disabled
[1] = External Frame Trigger
