RS.8D.M1.22 AK2-SC 255 Reference Manual 17
Once at suction configuration menu shown at right above, select the suction group you
want to configure and press ENTER. The Suction Info screen for that group will
appear as at right below. As you configure, questions may appear that are not
included on the default screen. The screen at left below shows all the possible lines
revealed.
The fields and their contents are as follows:
Suction I.D. (2 label fields: the first is a list box: A to Z; the second
is 9 characters not constrained) This is the identifica-
tion you wish to assign to the suction group. The entry
will modify the screen title. For example, if you enter a
B in the first field and Low Temp in the second, the
right portion of the screen title for the configuration
and status screens for this group will read Low Temp
AB.
PSIG target (-50.0 to 500.0) The pressure that the controller will
maintain, subject to capabilities of mechanical equip-
