60 AK2-SC 255 Reference Manual RS.8D.M1.22
Upload (Button field) Placing the cursor on this field and
pressing ENTER will cause information programmed
at the fixture on the EKC to be uploaded to the AKC
55 controller.
Wink (EKC) Wink (Button field) Placing the cursor on this field and
pressing ENTER will cause this individual EKC to blink
its display for a short time so that its fixture can be
identified.
Degree Master
Board & Points After Degree Master controllers have been configured and addressed (in accordance
with the Danfoss manual Degree Master in AKC 55 Systems (literature number
RS.8B.F1.22 (or update), code number 084R9897) you need to re-scan the network
so that they are recognized, then initialize them. This is done from the Degree Master
Controls Board & Points screen. From any Configuration Board & Points, Other
Controllers screen, select the Degree Master Icon and press ENTER. This screen
appears. Our example shows only one circuit, but every configured Degree Master
circuit will be listed.
The fields and contents are:
Name (Label field: any 15 characters) The name of the
evaporator being controlled by the Degree Master. The
default names for the Degree Master circuits automati-
cally added during configuration of refrigeration are
shown, and will suffice in many applications. They can
be edited character by character (put the cursor on the
field, press +/- to change to edit mode; then use the left
and right arrow keys to move from space to space and
the up and down arrow keys to select the character for
that space. When the name appears as you want it,
press ENTER).
Address (0 to 99) Enter an address from 1 to 99 that is unique
