Danfoss VLT AHF 005

130BE064.10
1
3
2
1 Outlet for outgoing airow
2 Inlet for ingoing airow
3 AHF lter
Illustration 4.9 Wrong Installation - Airow Bypassing the Filter
- Side View
Correct installation
Illustration 4.10 shows a lter installed in a narrow cabinet.
Here, the airow is not able to bypass the lter, and air
baes are therefore not required.
1
2
3
130BE065.10
1 Outlet for outgoing airow
2 Inlet for ingoing airow
3 AHF lter
Illustration 4.10 Correct Installation in Narrow Cabinets -
Airow Passing Through the Filter
Illustration 4.11 and Illustration 4.12 show correct instal-
lation in deep/wide cabinets. Here, the air baes guide the
airow through the lter and provides cooling.
Requirements for Installati...
VLT
®
Advanced Harmonic Filter AHF 005/AHF 010
24 Danfoss A/S © 10/2016 All rights reserved. MG80C502
