130BF357.10
467 (18.4)
0.0
52 (2.1)
0.0
99 (3.9)
145 (5.7)
1
2
3
4
1 Mains terminals 3 Brake terminals
2 Ground terminals 4 Motor terminals
Figure 8.45 D6h Terminal Dimensions with Circuit Breaker Option (Front View)
Exterior and Terminal Dimen...
VLT
®
AQUA Drive FC 202
98 Danfoss A/S © 01/2018 All rights reserved. MG22B222
