Danfoss VLT AQUA Drive FC 202 Design Manual

8.7.2 D7h Terminal Dimensions
130BF359.10
0.0
0.0
2
1
372 (14.7)
412 (16.2)
395 (15.6)
515 (20.3)
66 (2.6) 95 (3.7)
131 (5.1) 151 (5.9) 195 (7.7) 238 (9.4)
292 (11.5) 346 (13.6)
49 (1.9)
198 (7.8)
368 (14.5)
545 (21.4)
3
4
1 Mains terminals 3 Motor terminals
2 Brake terminals 4 Ground terminals
Figure 8.54 D7h Terminal Dimensions with Disconnect Option (Front View)
Exterior and Terminal Dimen... Design Guide
MG22B222 Danfoss A/S © 01/2018 All rights reserved. 107
8 8
