Danfoss VLT AQUA Drive FC 202 Design Manual

8.10.2 E2h Terminal Dimensions
130BF689.10
721 (28.4)
6X 613 (24.1)
1
515 (20.3)
485 (19.1)
0 (0.0)
200 (7.9)
185 (7.3)
0 (0.0)
101 (4.0)
89 (3.5)
289 (11.4) 281 (11.1)
195 (7.7)
483 (19.0) 409 (16.1) 387 (15.2) 597 (23.5) 579 (22.8) 503 (19.8)
479 (18.9) 568 (22.4) 519 (20.4) 608 (23.9)
2
3
4
1 Mains terminals 3 Motor terminals
2 Brake or regen terminals 4 Ground terminals, M10 nut
Figure 8.80 E2h Terminal Dimensions (Front View)
Exterior and Terminal Dimen... Design Guide
MG22B222 Danfoss A/S © 01/2018 All rights reserved. 133
8 8
